DIAMOND (WHEEL, CORE BIT, PIN DRILL)

Diamond Blades, Core Bits & Pin Drills in Singapore

Shop diamond blades, diamond core bits and diamond pin drills in Singapore at A.C.T. Hardware. Choose from diamond wheels for angle grinders and cutters, plus vacuum brazed core bits and pin drills, for cutting and drilling tile, granite, marble, concrete, brick and metal.

Diamond tools use industrial diamond grit bonded to a steel body so they can cut very hard materials that ordinary abrasives cannot. Segmented and turbo rims cut fast on concrete and stone, continuous rims give chip-free cuts in tile and glass, and vacuum brazed wheels cut and drill in more demanding materials. Core bits cut large round holes, and pin drills make small holes in tile and stone.

How to Choose the Right Diamond Blade or Core Bit

• Material – match the rim to the job: segmented for concrete and brick, continuous rim for tile and porcelain, corrugated or wave types for granite and marble.
• Wet or dry use – some wheels are meant for water cooling and others for dry cutting, so check the marking before use.
• Diameter and bore – the wheel size must suit your grinder or cutter, and the arbor or thread (such as M10 or M14) must match.
• Finish quality – fine-work rims leave cleaner edges for visible cuts, while rough-work types remove material faster.
• Application type – choose core bits for round holes and pin drills for small holes in tile or stone.

Common Applications

• Cutting floor and wall tiles during HDB and condo renovation
• Chasing and cutting concrete and brick on construction sites
• Cutting granite and marble worktops in fabrication workshops
• Drilling openings for pipes and conduits in M&E works
• Trimming metal and multi-material surfaces in maintenance jobs

Brands Available

Browse trusted brands including MAKITA.

Not sure which one suits your job? WhatsApp us at +65 8978 9808 and our team will be happy to advise.
